CFM56 Leap 1A - A Two Spool Unmixed Flow Turbofan



The CFM International LEAP ("Leading Edge Aviation Propulsion") is a high-bypass turbofan engine produced by CFM International, a 50–50 joint venture between the American GE Aerospace and the French Safran Aircraft Engines. It competes with the Pratt & Whitney PW1000G for narrow-body aircraft.







https://leehamnews.com/2024/08/30/bjorns-corner-new-engine-development-part-22-high-turbine-technologies/

EASA_E110_TCDS_Issue_13_LEAP-1A-1C.pdf
